AuviTran AVDT-BOB-AS8IO

Description

The AVDT-BOB is a compact Dante break out box with embedded Digital Signal Processing.
The AVDT-BOB has state-of-the-art analog microphone preamplifiers for a very high audio dynamic and quality over Dante at a very contained price:
• 4x Dante input channels and 4x Dante output channels with Dante routing
• 2x or 4x Mic/Line balanced inputs with independent phantom +48V
• 2x or 4x Analog balanced outputs
• 60dB gain range by 3dB step with Input Noise (EIN) as low as -125dBu
• Stereo AES/EBU Input and Output on Euroblock (-ADE- Versions) or on SUBD25 (-ADX- Versions)
• 4x Analog GPIOs for remote control on Euroblock (-ADE- Versions) or on SUBD25 (-ADX- Versions)
The AVDT-BOB has a DSP to process and mix audio signal at the source and at the output. The AVDT-BOB features a dual core ARM processor associated with a large amount of flash memory for a universal and multiplatform remote control over IP (iOS, Android, Windows, Mac OS, Linux). They provide to the AVDT-BOB a powerful processing with an efficient, easy and smart remote control:
• Smart embedded DSP for advanced internal audio mixing and effect processing
• 4 independent mixers of the 6x to 8x inputs
• 8 equalizations and 8 limiters compressors
• Build-in dual ARM RISC processor with Web 2.0 HTML5 interface
• Direct remote without any installation via Mac OSX, Windows, and Linux computer or via iPad, iPhone or Tablet, Smartphone
